凯斯零件查询(RS551) - CASE IH ROUND BALER (1/99-12/00) (6-12) - BELT TENSIONING ROLLER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
736 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700135537
|
[1] |
SUPPORT
|
HFI
WA - outer, upper (Includes item 7)
|
| 2. |
062448
|
[1] |
3/16 X 1-3/4 COTTER PIN
|
|
| 3. |
705574
|
[1] |
WASHER,1 1/8" x 2" x .156", HDN
|
CAS
|
| 4. |
700135516
|
[1] |
PIN
|
HFI
|
| 5. |
7701279
|
[1] |
BOLT
|
HFI
1/2-13 X 5 C Superseded by part number: 87997
|
| 6. |
704742
|
[1] |
ROD
|
NNA
1/2-13 HFTLN GR/G Superseded by part number: 231-5348, 231-5348, 86516877
|
| 7. |
700716064
|
[1] |
BUSHING
|
CAS
- bronze
|
| 8. |
700135518
|
[1] |
TUBE,0.562" ID, 25.4 mm OD, 102 mm Length
|
HFI
|
| 9. |
700135519
|
[1] |
GUIDE
|
HFI
WA - belt
|
| 10. |
077016
|
[1] |
1/4-28 ZERK
|
|
| 11. |
700135700
|
[1] |
ARM
|
HFI
WA - upper
|
| 12. |
700124615
|
[2] |
ROLLER
|
CAS
ASSEMBLY (Includes item 15)
|
| 13. |
7883382
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 X 1 HWHMS Superseded by part number: 87034804
|
| 14. |
704734
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 15. |
8050825
|
[4] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 16. |
700100927
|
[4] |
HUB
|
L
|
| 17. |
700707981
|
[4] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
3/4-10 X 1-3/4 HSFCHCS
|
| 18. |
062299
|
[1] |
1/4 X 1-1/2 COTTER PIN
|
|
| 19. |
700710292
|
[1] |
PIN
|
CAS
1 CLEVIS PIN - special
|
