凯斯零件查询(RS551) - CASE IH ROUND BALER (1/99-12/00) (6-20) - TWINE THREADER SUPPORT ASSEMBLIES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
815 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-48
|
[2] |
BOLT,Hex, 1/4" - 20 x 1/2", Gr 5
|
CAS
1/4-20 X 1/2 C Superseded by part number: 88542
|
| 2. |
7774839
|
[4] |
LOCK NUT
|
CAS
1/4-20 HTLN GR/B Superseded by part number: 280129
|
| 3. |
700122987
|
[2] |
GUIDE
|
CAS
- twine
|
| 4. |
700707665
|
[2] |
LARGE PLATE
|
IH
SPRING - leaf
|
| 5. |
700135660
|
[1] |
ARM
|
HFI
WA - twine
|
| 6. |
700135164
|
[1] |
ROD
|
HFI
- threaded, 1/4-20
|
| 7. |
704007
|
[2] |
NUT,1/4"-20, G5
|
CAS
1/4-20 H Superseded by part number: 7770
|
| 8. |
704189
|
[2] |
NUT
|
CAS
1/4-20 HJN GR2 Superseded by part number: 87305
|
| 9. |
700132413
|
[1] |
ARM
|
HFI
WA - twine
|
| 10. |
7883374
|
[2] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 255918
|
| 11. |
704734
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 12. |
7703457
|
[2] |
HYD CONNECTOR,Hex, 1/4" - 20 x 3/4", Gr 5
|
NNA
1/4-20 X 3/4 C Superseded by part number: 413-412, 413-412, 86516954
|
| 13. |
700132412
|
[1] |
PLATE
|
HFI
|
| 14. |
700150123
|
[1] |
GUIDE
|
HFI
WA - right, plated Superseded by part number: 280634, 700159023, 87398, 700159021
|
| 15. |
700135090
|
[1] |
LEVER
|
HFI
WA Superseded by part number: 38-11016, 87398, 700159021, 700159023
|
| 16. |
062349
|
[1] |
.148 WIRE HAIR PIN COTTER
|
|
| 17. |
700135093
|
[1] |
PLATE
|
HFI
|
| 18. |
700707432
|
[1] |
SPRING
|
L
- extension
|
| 19. |
6869382
|
[2] |
SPACER
|
HFI
|
| 20. |
700150125
|
[1] |
SUPPORT
|
HFI
WA
|
| 21. |
700711084
|
[2] |
BOLT
|
CAS
3/8-16 X 1-1/2 HFS GR8
|
| 22. |
700107983
|
[1] |
GUIDE
|
HFI
|
