凯斯零件查询(RS551) - CASE IH ROUND BALER (1/99-12/00) (6-22) - BALE SHAPE MONITOR ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
357 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700132176
|
[2] |
SUPPORT
|
HFI
WA
|
| 2. |
7883382
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 X 1 HWHMS Superseded by part number: 87034804
|
| 3. |
704247
|
[4] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| 4. |
700707010
|
[2] |
CLAMP
|
CAS
Superseded by part number: 86572009
|
| 5. |
7771322
|
[2] |
BOLT,Hex Serr, 5/16" - 18 x 1/2"
|
CAS
5/16-18 X 1/2 HFSS Superseded by part number: 256873
|
| 6. |
700132519
|
[1] |
COVER
|
HFI
- wire
|
| 7. |
7827983
|
[1] |
GROMMET
|
CAS
|
| 8. |
700710130
|
[2] |
SPRING
|
CAS
- extension
|
| 9. |
7701675
|
[3] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5
|
CAS
1/2-13 X 2 C Superseded by part number: 9706716
|
| 10. |
705541
|
[6] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 11. |
704742
|
[3] |
ROD
|
NNA
1/2-13 HFTLN GR/G Superseded by part number: 231-5348, 231-5348, 86516877
|
| 12. |
7058266
|
[2] |
SPRING
|
IH
- compression
|
| 13. |
700135686
|
[1] |
SUPPORT
|
HFI
WA
|
| 14. |
700715009
|
[3] |
FRONT IDLER
|
CAS
IDLER - rubber tire Superseded by part number: 111767C2
|
| 15. |
703769
|
[2] |
SCREW
|
CAS
5/16-18 X 2 3/4 C
|
| 16. |
700709602
|
[4] |
WASHER,5/16"
|
CAS
5/16 WIDE PLAIN WASHER Superseded by part number: 495-61034
|
| 17. |
704163
|
[2] |
LOCK NUT
|
CAS
5/16-18 HTLN GR/B Superseded by part number: 230-4145
|
| 18. |
077040
|
[4] |
1/4-28 X 45 DEGREE ZERK
|
|
