凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (09-038) - RIENK KIT (S.N. CFH0156001 THRU CFH0156399) (TO BE ORDERED THRU WHOLEGOODS ONLY) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
764 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
51292
|
[2] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
spherical Superseded by part number: 84330041, 47508357
|
| 2. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
|
| 3. |
700135180
|
[1] |
SPROCKET ASSY.
|
HFI
WA 15 tooth
|
| 4. |
249-1
|
[1] |
KEY
|
IH
gib, 1/4 x 1-3/4
|
| 5. |
241-1718
|
[2] |
LINK,25.4mm Pitch
|
CAS
offset, #80 R/C
|
| 6. |
433-620
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
Superseded by part number: 86508773
|
| 7. |
231-4116
|
[6] |
NUT,3/8"-16, GB
|
CAS
hex top lock, 3/8-16 GR/B Superseded by part number: 88902, E64197
|
| 8. |
700132995
|
[7] |
WHEEL
|
HFI
REINK WA
|
| 9. |
700726045
|
[1] |
BUSHING,32.8 mm ID x 50.8 mm OD x 38 mm
|
HFI
delrin
|
| 10. |
700153659
|
[1] |
SUPPORT
|
HFI
WA
|
| 11. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 12. |
8701237
|
[2] |
BOLT
|
CAS
SCREW hex flange, 1/2-13 x 1-1/2 GR. 8
|
| 13. |
231-5348
|
[2] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
hex flange top lock, 1/2-13 GR/G Superseded by part number: 86521610
|
| 14. |
433-628
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
|
CAS
round head square neck, 3/8-16 x 1-3/4 Superseded by part number: 86508775
|
| 15. |
705541
|
[3] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2
|
| 16. |
700135179
|
[3] |
SPACER
|
HFI
|
| 17. |
700151477
|
[1] |
SHAFT
|
HFI
hex
|
| 18. |
700151528
|
[2] |
WHEEL
|
HFI
REINK WA outer
|
| 19. |
700150196
|
[1] |
SPACER
|
HFI
|
