凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (09-036) - BELT GUIDE KIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
816 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
433-620
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
Superseded by part number: 86508773
|
| 2. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 3. |
700132788
|
[1] |
ROD
|
HFI
|
| 4. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2
|
| 5. |
432-1016
|
[2] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 6. |
700132782
|
[1] |
GUIDE
|
HFI
WA lower
|
