| 1. |
1791D
|
[4] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
roller, #50 (10 foot bulk)
|
| 2. |
241-1315
|
[4] |
LINK, CONNECTING
|
CAS
#50 R/C Superseded by part number: 87034815
|
| 3. |
7086002
|
[1] |
CHAIN (AG)
|
CAS
roller, #60 (10 foot bulk) Superseded by part number: 611362R91X, 241-1316
|
| 4. |
241-1316
|
[1] |
LINK,19.05mm Pitch
|
CAS
connector, #60 R/C
|
| 5. |
195-2139
|
[3] |
WASHER,36.52mm ID x 57.15mm OD x 2.03mm Thk
|
IH
BUSHING narrow rim machinery, 1-3/8 x 14 gauge
|
| 6. |
Q3936
|
[1] |
KEY,Gib, 5/16" Sq x 2 1/2"
|
IH
|
| 7. |
700133291
|
[1] |
CLUTCH
|
HFI
ASSEMBLY
|
| 8. |
700134911
|
[1] |
HUB
|
HFI
ASSEMBLY
|
| 9. |
703736
|
[1] |
BOLT,Hex, 1/2" - 13 x 2 3/4", Gr 5
|
CAS
SCREW hex cap, 1/2-13 x 2-3/4
|
| 10. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 11. |
413-536
|
[6] |
BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 86505972
|
| 12. |
492-11031
|
[6] |
LOCK WASHER,5/16"
|
CAS
Superseded by part number: 83990583
|
| 13. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 14. |
700716888
|
[2] |
SPROCKET ASSY.
|
CAS
idler, 17 tooth
|
| 15. |
6537526
|
[1] |
SPACER
|
HFI
|
| 16. |
95-81101
|
[2] |
WASHER,0.52" ID x 0.88" OD x 0.07" Thk
|
CAS
BUSHING narrow rim machinery, 1/2 x 14 gauge
|
| 17. |
700147510
|
[1] |
SPECIAL BOLT
|
HFI
DRAW WA-plated
|
| 18. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2
|
| 19. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 20. |
6234710
|
[1] |
SPACER
|
CAS
|
| 21. |
413-860
|
[1] |
BOLT,Hex, 1/2" - 13 x 3-3/4", Gr 5
|
CAS
Superseded by part number: 86505992
|
| 22. |
231-5348
|
[1] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
hex flange top lock, 1/2-13 GR/G Superseded by part number: 86521610
|
| 23. |
Q3947
|
[1] |
KEY,Gib, 3/8" Sq x 1 1/2"
|
IH
|
| 24. |
700150117
|
[1] |
SPROCKET ASSY.
|
HFI
WA 27 tooth
|
| 25. |
700715085
|
[1] |
BRONZE BUSHING
|
HFI
bronze
|
| 26. |
700150114
|
[1] |
SPROCKET ASSY.
|
HFI
WA 25 tooth
|
| 27. |
61747
|
[1] |
KEY
|
CAS
gib, 1/2 x 2-1/2
|
| 28. |
700135556
|
[1] |
SPACER
|
HFI
|
| 29. |
83-13810
|
[2] |
SET SCREW,Hex Soc, 3/8"-16 x 5/8"
|
CAS
cup point hex socket, 3/8-16 x 5/8 NP
|
| 30. |
425-146
|
[2] |
JAM NUT,3/8" - 16, Gr 5
|
CAS
Superseded by part number: 87016560
|
| 31. |
700717790
|
[1] |
SPROCKET ASSY.
|
CAS
WA 17, 27, 24 tooth (Includes: Ref. 25)
|
