卡特零件查询（725C2） 250-1725: MOUNTING GP-TRANSFER GEAR
广数供应链运营团队, 15 02月, 2025，浏览：
390 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6Y-6884 | [2] | SLEEVE-TAPERED | |
| 2. | 6Y-9960 | [2] | MOUNT AS | |
| | | | (EACH INCLUDES) |
| | 9W-8095 | [1] | PAD-REBOUND | |
| 3. | 237-8953 | [1] | BRACKET(LH) | |
| 4. | 237-9554 | [1] | BRACKET(RH) | |
| 5. | 7X-2553M | [16] | BOLT(M16X2X40-MM) | |
| 6. | 7X-2563M | [2] | BOLT(M20X2.5X60-MM) | |
| 7. | 8C-3290M | [2] | BOLT(M24X3X150-MM) | |
| 8. | 8T-4001M | [2] | NUT(M24X3-THD) | |
| 9. | 8T-4123 | [4] | WASHER(22X35X3.5-MM THK) | |
| 10. | 8T-4131M | [2] | NUT(M20X2.5-THD) | |
| 11. | 8T-4167 | [4] | WASHER-HARD(26X44X4-MM THK) | |
| 12. | 8Y-7119 | [2] | WASHER(26X144X12-MM THK) | |
| 13. | 9X-8257 | [16] | WASHER(17.5X30X3.5-MM THK) | |
| | M | | METRIC PART |
