凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (04-022) - ELECTRICAL CONTROL BOXES AND CABLE ASSEMBLIES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
387 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
22-824
|
[2] |
CABLE TIE,3/16" x 7 1/4"
|
IH
CABLE STRAP Superseded by part number: 529070
|
| 2. |
700707683
|
[2] |
DECAL
|
CAS
notice, 12 volt
|
| 3. |
700717795
|
[1] |
HARNESS
|
CAS
CABLE ASSEMBLY
|
| 4. |
700715692
|
[1] |
HARNESS
|
L
control (without mesh wrap)
|
| 4. |
700717507
|
[1] |
HARNESS
|
CAS
control (with mesh wrap)
|
| 5. |
700717823
|
[1] |
CABLE
|
CAS
ASSEMBLY
|
| 6. |
700716953
|
[1] |
CASE
|
L
CONTROL BOX ASSEMBLY COMPLETE (without mesh wrap)
|
| 7. |
700151501
|
[1] |
SUPPORT
|
HFI
BRACKET mounting, control box (without mesh wrap)
|
| 8. |
700151500
|
[1] |
SUPPORT
|
HFI
BRACKET mounting, control box (with mesh wrap)
|
| 9. |
700718052
|
[1] |
CONTROL
|
CAS
BOX ASSEMBLY COMPLETE (with mesh wrap)
|
| 10. |
700718048
|
[1] |
CABLE ASSY.
|
CAS
(cable for imported tractors only)
|
| 11. |
700707598
|
[1] |
WIRE HARNESS
|
IH
ASSEMBLY
|
