神钢零件查询(F4HFE6131 A005) - ENGINE 5801425077 - 84387924 (1/11-) (10.105.01) - CONNECTING ROD Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
786 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [6] | CONNECTING ROD | TOR- ASSY, Inc. 2 -5 |
| 1. | 2831298R | [6] | REMAN-CONNECTING ROD | TOR |
| 1. | 2831298C | [6] | CORE-ROD CONNECTING | TORReturn Number |
| 2. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONInc. 4, 5 |
| 4. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 6. | 2856309 | [6] | CRANKSHAFT BEARING | BHB |
| 7. | 8093882 | [1] | BEARING SET | TORConnecting Rod Bearing, Standard |
| 7. | 8094960 | [1] | BEARING SET,(-0.250) | TORConnecting Rod Bearing, Undersize, 0.25 mm |
| 7. | 8094961 | [1] | BEARING SET,(-0.500) | TORConnecting Rod Bearing, Undersize, 0.50 mm |
