凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (07-014) - SHIELD ASSEMBLIES (FRONT) (S.N. CFH0156400 AND LATER) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
869 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
hex flange top lock, 5/16-18 GR/G
|
| 2. |
700135586
|
[1] |
GUIDE
|
HFI
WA
|
| 3. |
7745003
|
[1] |
GUIDE
|
L
|
| 4. |
51200861
|
[1] |
U-BOLT
|
BRR
|
| 5. |
281-34912
|
[2] |
SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
hex washer head thread cutting tapping, 3/8-16 x 3/4
|
| 6. |
700135587
|
[1] |
SHIELD
|
HFI
left
|
| 7. |
409-7612
|
[24] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 8. |
232-5316
|
[28] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 9. |
700135589
|
[1] |
SHIELD
|
HFI
right
|
| 10. |
700135592
|
[1] |
SHIELD
|
HFI
|
| 11. |
700135613
|
[1] |
ROD
|
HFI
|
| 12. |
700132983
|
[1] |
PANEL
|
HFI
|
| 13. |
700132757
|
[1] |
HINGE
|
HFI
WA left
|
| 14. |
700132758
|
[1] |
HINGE
|
HFI
WA right
|
| 15. |
700132760
|
[1] |
SHIELD
|
HFI
|
| 16. |
700150143
|
[1] |
SUPPORT
|
HFI
upper
|
