凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (07-012) - SHIELD ASSEMBLIES (FRONT) (S.N. CFH0156001 THRU CFH0156399) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1007 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
hex flange top lock, 5/16-18 GR/G
|
| 2. |
700135586
|
[1] |
GUIDE
|
HFI
WA
|
| 3. |
7745003
|
[1] |
GUIDE
|
L
|
| 4. |
51200861
|
[1] |
U-BOLT
|
BRR
|
| 5. |
281-34912
|
[2] |
SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
hex washer head thread cutting tapping, 3/8-16 x 3/4
|
| 6. |
409-7612
|
[28] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 7. |
232-5316
|
[30] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 8. |
700135587
|
[1] |
SHIELD
|
HFI
left
|
| 9. |
700135589
|
[1] |
SHIELD
|
HFI
right
|
| 10. |
700150180
|
[1] |
SUPPORT
|
HFI
|
| 11. |
700135592
|
[1] |
SHIELD
|
HFI
|
| 12. |
700135613
|
[1] |
ROD
|
HFI
|
| 13. |
292504A1
|
[1] |
CASE
|
CAS
RECEPTACLE
|
| 14. |
700150181
|
[1] |
SUPPORT
|
HFI
|
| 15. |
360-816
|
[2] |
BOLT,Hex, 1/2" - 13 x 1", Gr 8
|
CAS
hex flange, 1/2-13 x 1 GR. 8 Superseded by part number: 87034823
|
| 16. |
340-1108
|
[2] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
cross recess pan head machine, #10-24 x 1/2 GR. 60M
|
| 17. |
495-31022
|
[2] |
WASHER,#10
|
CAS
Superseded by part number: 88612
|
| 18. |
492-11010
|
[2] |
LOCK WASHER,#10
|
CAS
Superseded by part number: 80684
|
| 19. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 20. |
700135584
|
[1] |
PANEL
|
HFI
|
| 21. |
700135578
|
[1] |
SHIELD
|
HFI
|
| 22. |
700132465
|
[1] |
HINGE
|
HFI
WA right
|
| 23. |
700714706
|
[1] |
LATCH
|
CAS
900 turn
|
| 24. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 25. |
700132462
|
[1] |
HINGE
|
HFI
WA left
|
| 26. |
700150143
|
[1] |
SUPPORT
|
HFI
upper
|
