凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (07-050) - MESH WRAP SHIELD ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
200 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
409-7612
|
[12] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 2. |
496-81010
|
[32] |
WASHER
|
CAS
hardened wide plain, 3/8 Superseded by part number: 86625244
|
| 3. |
700717030
|
[1] |
BUSHING
|
CAS
|
| 4. |
6523799
|
[1] |
BUSHING
|
CAS
tensioner
|
| 5. |
6270888
|
[2] |
BUSHING
|
CAS
SPACER
|
| 6. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
hex flange, 3/8-16 x 1-1/4 GR. 8 Superseded by part number: 87327172
|
| 7. |
700148582
|
[1] |
LATCH
|
HFI
WA
|
| 8. |
700720033
|
[1] |
LATCH
|
CAS
|
| 9. |
433-520
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
CAS
BOLT, round head square neck, 5/16-18 x 1-1/4 Superseded by part number: 280507
|
| 10. |
495-61034
|
[1] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
wide plain, 5/16
|
| 11. |
232-5315
|
[1] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
hex flange top lock, 5/16-18 GR/G
|
| 12. |
700148756
|
[1] |
SUPPORT
|
HFI
WA
|
| 13. |
433-612
|
[8] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 14. |
232-5316
|
[12] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 15. |
7883275
|
[4] |
SCREW,Hex Washer, 1/4" - 20 x 3/4"
|
CAS
hex washer head machine, 1/4-20 x 3/4
|
| 16. |
700711876
|
[4] |
LOCK NUT
|
CAS
hex flange top lock, M10 x 1.5 class 9
|
| 17. |
700717029
|
[2] |
CYLINDER ASSY.
|
CAS
GAS spring (Includes: Ref. 18)
|
| 18. |
700718303
|
[4] |
JOINT
|
CAS
ball, 14-28
|
| 19. |
700148806
|
[1] |
SHIELD
|
HFI
WA
|
| 20. |
700152035
|
[2] |
BUSHING
|
HFI
|
| 21. |
495-21031
|
[4] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701, 72187262
|
