纽荷兰零件查询(DC85) - CRAWLER DOZER (8/04-) (02-12) - OIL PUMP, PAN New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
725 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899020 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 2. | 4899091 | [22] | SCREW,Hex Flange Cap, M8 x 1.25 x 40.00mm | BAS |
| 2. | 4895489 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 110mm | TOR |
| 3. | 4898301 | [1] | GASKET,0.42mm Thk | TOR |
| 4. | 2852011 | [1] | ENGINE OIL PAN | TOR |
| 5. | 2853728 | [1] | O-RING,M23.47 ID x 2.62 Thk | TOR Superseded by part number: 14457780 |
| 6. | 4894139 | [1] | PLUG,Hex Soc, M22 x 1.5 | TORDoes Not Include Seal, Purchase Seal Separately |
| 7. | 2852012 | [1] | OIL PAN GASKET SET | TOR Superseded by part number: 504069777 |
| 8. | 2852016 | [1] | SPACER | TORIf Used Superseded by part number: 504062812 |
| 9. | 2852013 | [1] | STRAINER ELEMENT | TORTube; Oil Suction; Includes Screen Which Is Not Serviced Separately Superseded by part number: 504042165 |
| 10. | 4895538 | [1] | FLANGE BOLT,Hex, M10 x 1.5 x 120mm | TOR Superseded by part number: 16599025 |
