纽荷兰零件查询(DC85) - CRAWLER DOZER (8/04-) (02-15) - FLYWHEEL HOUSING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
522 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899026 | [2] | DOWEL,M18 x 10 | TOR |
| 2. | 4899109 | [3] | SCREW,Hex, M10 x 1.5 x 80 | BASFlange |
| 3. | 4892915 | [7] | FLANGE BOLT,Hex, M10 x 1.5 x 40mm | TOR |
| 3. | 4899143 | [1] | SCREW,Hex Flg, M10 x 1.5 x 140 | TOR |
| 4. | 4895378 | [2] | BUTTON PLUG,M29.2 | TORDoes Not Include Seal, Purchase Seal Separately |
| 5. | 4895379 | [2] | O-RING,21.82mm ID x 3.53mm Width | TOR Superseded by part number: 17288480 |
| 6. | 4899076 | [5] | SCREW,Hex Flg, M12 x 1.75 x 80 | TOR |
| 7. | 4899074 | [2] | SCREW,Hex Flg, M12 x 1.75 x 120 | TOR |
| 8. | 4890833 | [1] | OIL SEAL,M130 x 155 x 12.5/16 | TOR Superseded by part number: |
| 9. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
| 10. | 2852023 | [1] | COVER | TORFlywheel Housing Superseded by part number: 2855178, 2855183 |
| 11. | 4895155 | [1] | COVER | TOR |
| 12. | 2852025 | [1] | COVER | TORCOVER, Fuel Pump Gear |
| 13. | 4899020 | [3] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 13. | 2852865 | [2] | FLANGE BOLT,Hex, Shldr, Lkg, M10 x 33mm | TOR Superseded by part number: 504080094 |
| 14. | 4895079 | [1] | PIPE PLUG,3/4"-14 | TOR |
