| 1. |
432-1228
|
[1] |
COTTER PIN,3/16" x 1 3/4"
|
CAS
Superseded by part number: 87399
|
| 2. |
705574
|
[1] |
WASHER,1 1/8" x 2" x .156", HDN
|
CAS
|
| 3. |
700135516
|
[1] |
PIN
|
HFI
|
| 4. |
700707437
|
[1] |
COUNTER
|
CAS
BALE
|
| 5. |
700135511
|
[1] |
SUPPORT
|
HFI
WA outer, lower (Includes: Ref. 15)
|
| 6. |
413-880
|
[1] |
BOLT,Hex, 1/2" - 13 x 5", Gr 5
|
CAS
SCREW hex cap, 1/2-13 x 5 Superseded by part number: 87997
|
| 7. |
231-5348
|
[1] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
hex flange top lock, 1/2-13 GR/G Superseded by part number: 86521610
|
| 8. |
700707981
|
[8] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
hex socket flat countersunk head cap, 3/4-10 x 1-3/4
|
| 9. |
700150222
|
[1] |
PLATE
|
HFI
|
| 10. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 11. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 12. |
700135518
|
[1] |
TUBE,0.562" ID, 25.4 mm OD, 102 mm Length
|
HFI
|
| 13. |
700716222
|
[1] |
SPRING
|
CAS
extension
|
| 14. |
432-824
|
[1] |
COTTER PIN,1/8" x 1 1/2"
|
CAS
Superseded by part number: 80708
|
| 15. |
700716063
|
[1] |
BUSHING
|
CAS
bronze
|
| 16. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 17. |
69500
|
[1] |
SET SCREW
|
HFI
cup point hex socket, 1/4-28 NP Superseded by part number: 87042
|
| 18. |
700135493
|
[1] |
ARM
|
HFI
WA lower
|
| 19. |
700150042
|
[1] |
ROLLER
|
HFI
ASSEMBLY (Includes: Ref. 26 & 27)
|
| 20. |
432-1020
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
Superseded by part number: 86523851
|
| 21. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
5/8" bolt size Superseded by part number: 87613283
|
| 22. |
700716026
|
[1] |
PIN
|
CAS
clevis, 5/8-2-1/4
|
| 23. |
700150040
|
[2] |
WASHER
|
HFI
WA special
|
| 24. |
700150036
|
[2] |
GUIDE
|
HFI
WA
|
| 25. |
700150043
|
[1] |
ROLLER
|
HFI
ASSEMBLY (Includes: Ref. 26 & 27)
|
| 26. |
8050825
|
[8] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
cylindrical Superseded by part number: F82059
|
| 27. |
700150048
|
[2] |
SHAFT
|
HFI
|
| 28. |
700710292
|
[2] |
PIN
|
CAS
|
| 29. |
432-1624
|
[2] |
COTTER PIN,1/4" x 1 1/2"
|
CAS
Superseded by part number: 80753
|
