凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (06-022) - TENSIONING MOUNTING ASSEMBLY (RIGHT) (S.N. CFH0156400 AND LATER) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
248 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700132903
|
[1] |
SPACER
|
HFI
|
| 2. |
700132885
|
[1] |
SUPPORT
|
HFI
WA R, lower
|
| 3. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 4. |
700132870
|
[2] |
SPECIAL PIN
|
HFI
WA
|
| 5. |
413-680
|
[1] |
BOLT,Hex, 3/8" - 16 x 5", Gr 5
|
CAS
Superseded by part number: 280177
|
| 6. |
232-5316
|
[3] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 7. |
700132891
|
[1] |
TUBE,25.4 mm OD, 102.5 mm Length
|
HFI
SPACER
|
| 8. |
700132889
|
[1] |
SUPPORT
|
HFI
WA upper
|
| 9. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
