凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (06-020) - TENSIONING MOUNTING ASSEMBLY (RIGHT) (S.N. CFH0156001 THRU CFH0156399) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
920 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700153656
|
[1] |
SUPPORT
|
HFI
WA R, lower
|
| 2. |
700713418
|
[1] |
HOSE,0.14" ID x 41.00"
|
CAS
Lube
|
| 3. |
700713413
|
[1] |
NUT
|
CAS
1/8-27 NPSM Superseded by part number: 76085536
|
| 4. |
700132870
|
[1] |
SPECIAL PIN
|
HFI
WA
|
| 5. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 6. |
700153655
|
[1] |
SUPPORT
|
HFI
WA R, upper
|
| 7. |
219-402
|
[1] |
ADAPTER,90 Degree, 1/4"-1/8 NPTF
|
CAS
CONNECTOR, ELBOW-90°
|
| 8. |
700711084
|
[2] |
BOLT
|
CAS
SCREW hex flange, 3/8-16 x 1-1/2 GR. 8
|
| 9. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 10. |
700132954
|
[1] |
SPECIAL PIN
|
HFI
WA
|
