| 1. |
409-7612
|
[1] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 2. |
232-5316
|
[7] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 3. |
413-860
|
[1] |
BOLT,Hex, 1/2" - 13 x 3-3/4", Gr 5
|
CAS
Superseded by part number: 86505992
|
| 4. |
700711557
|
[2] |
WASHER
|
CAS
hardened wide plain, 1/2
|
| 5. |
231-5348
|
[2] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
hex flange top lock, 1/2-13 GR/G Superseded by part number: 86521610
|
| 6. |
413-888
|
[1] |
BOLT,Hex, 1/2" - 13 x 5-1/2", Gr 5
|
CAS
SCREW hex cap, 1/2-13 x 5-1/2 Superseded by part number: 88576
|
| 7. |
700135096
|
[1] |
SUPPORT
|
HFI
KNIFE
|
| 8. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 9. |
413-648
|
[1] |
BOLT,Hex, 3/8" - 16 x 3", Gr 5
|
CAS
Superseded by part number: 280161
|
| 10. |
496-81010
|
[3] |
WASHER
|
CAS
hardened wide plain, 3/8 Superseded by part number: 86625244
|
| 11. |
700718504
|
[1] |
SPRING
|
CAS
compression
|
| 12. |
700715132
|
[1] |
KNIFE
|
CAS
upper
|
| 13. |
700715133
|
[1] |
KNIFE
|
CAS
lower
|
| 14. |
700135101
|
[1] |
PLATE
|
HFI
|
| 15. |
413-412
|
[2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5
|
CAS
Superseded by part number: 9707580, 72187189
|
| 16. |
232-4114
|
[3] |
LOCK NUT,1/4"-20, GC
|
CAS
hex top, 1/4-20 GR/B Superseded by part number: 280129
|
| 17. |
61-3258
|
[1] |
HEX SOC SCREW,1/4"-20 x 1/2"
|
CAS
hex socket head cap, special, 1/4-20 x 1/2 Superseded by part number: 81960
|
| 18. |
700703692
|
[2] |
ADJUSTMENT ROD
|
L
ROD end
|
| 19. |
413-520
|
[1] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 87657
|
| 20. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
Superseded by part number: 72187067, 145458
|
| 21. |
700135094
|
[1] |
ROD
|
CAS
|
| 22. |
425-115
|
[2] |
NUT,5/16"-24, G5
|
CAS
Superseded by part number: 86629539
|
| 23. |
413-532
|
[1] |
BOLT,Hex, 5/16" - 18 x 2", Gr 5
|
CAS
Superseded by part number: 9636711
|
| 24. |
232-5315
|
[1] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
hex flange top lock, 5/16-18 GR/G
|
| 25. |
700117081
|
[1] |
SPACER
|
HFI
|
| 26. |
51200296
|
[1] |
SPRING
|
CAS
extension
|
| 27. |
700135057
|
[1] |
CLIP
|
HFI
|
| 28. |
413-620
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187207, 88011
|
| 29. |
6212740
|
[1] |
SPACER
|
CAS
|
| 30. |
700150118
|
[1] |
LEVER
|
HFI
WA
|
| 31. |
52258
|
[1] |
BUSHING
|
CAS
narrow rim machinery, 1 x 14 gauge
|
| 32. |
219-93
|
[2] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 33. |
700132382
|
[1] |
SPACER
|
HFI
TUBE
|
| 34. |
113-420
|
[1] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5, Full Thd
|
CAS
|
| 35. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 36. |
700135100
|
[1] |
LINK
|
HFI
|
| 37. |
432-1020
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
Superseded by part number: 86523851
|
| 38. |
066183
|
[1] |
CLEVIS
|
IH
Superseded by part number: 70937465
|
| 39. |
700708652
|
[1] |
CLEVIS PIN
|
HFI
1/2 x 1-27/64" Superseded by part number: 427-8150
|
| 40. |
700135097
|
[1] |
CRANK
|
HFI
WA
|
| 41. |
700135081
|
[1] |
TUBE,0.562" ID, 25.4 mm OD, 65 mm Length
|
HFI
|
| 42. |
700132652
|
[2] |
STOP
|
HFI
Superseded by part number: 700162210
|
| 43. |
121-237
|
[1] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
hex flange, 3/8-16 x 1-1/4 GR. 8 Superseded by part number: 87327172
|
