| 1. |
700135651
|
[1] |
SUPPORT
|
HFI
WA twine arm (Includes: Ref. 6) Superseded by part number: 700132687
|
| 2. |
413-524
|
[1] |
BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5
|
IH
Superseded by part number: 88275, 72187199
|
| 3. |
230-4115
|
[1] |
LOCK NUT,5/16"-18, GA
|
CAS
hex top lock, 5/16-18 GR/B Superseded by part number: 230-4145
|
| 4. |
700135662
|
[1] |
SHAFT
|
HFI
WA
|
| 5. |
219-93
|
[2] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 6. |
740514
|
[4] |
BUSHING,31.81mm ID x 38.2mm OD x 50.8mm L
|
L
BEARING bronze
|
| 7. |
495-81205
|
[4] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
BUSHING narrow rim machinery, 1-1/4 x 14 gauge
|
| 8. |
103-11125
|
[2] |
SNAP RING,#125, Ext
|
CAS
|
| 9. |
7721020
|
[4] |
HOSE CLAMP
|
CAS
|
| 10. |
700135805
|
[1] |
INDICATOR
|
HFI
WA
|
| 11. |
700135804
|
[1] |
BOLT
|
HFI
special
|
| 12. |
231-5348
|
[5] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
hex flange top lock, 1/2-13 GR/G Superseded by part number: 86521610
|
| 13. |
700716275
|
[1] |
HYDRAULIC HOSE,0.25" ID x 49.21", SAE 100R2 or SAE 100R16, SAE J517
|
CAS
|
| 14. |
100-11100
|
[1] |
SNAP RING,#100, Ext
|
CAS
Superseded by part number: 25121
|
| 15. |
409-7612
|
[1] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 16. |
231-5146
|
[5] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 17. |
700107977
|
[1] |
GUIDE
|
CAS
twine
|
| 18. |
515-23190
|
[1] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86624005
|
| 19. |
700135773
|
[1] |
PLATE
|
HFI
|
| 20. |
433-612
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 21. |
496-81010
|
[4] |
WASHER
|
CAS
hardened wide plain, 3/8 Superseded by part number: 86625244
|
| 22. |
700710984
|
[4] |
SCREW,Hex Flg, 1/2" x 1 1/4", G8 NC
|
CAS
|
