神钢零件查询(F4HFE6131 B003) - ENGINE 5801858658 IPU 280B TIER4 B (1/16-) (10.304.AL) - OIL PUMP & LINES, LINES Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
308 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84343612 | [1] | FILTER STRAINER | TORASSY, Incl 3, 4, 8, 9 Superseded by part number: 504388529 |
| 2. | NS | [1] | NOT SERVICED | BASScrew |
| 3. | 4898301 | [1] | GASKET,0.42mm Thk | TOR |
| 4. | 4897858 | [1] | SPACER | TOR |
| 5. | 4895291 | [1] | SCREW,Hex Flg, M10 x 1.5 x 20 | TOR |
| 6. | 2852234 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 7. | NS | [1] | NOT SERVICED | BASO-Ring |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONOil Suction Pipe, Incl in 1 |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONBracket, Incl in 2 |
