神钢零件查询(F4HFE6131 B003) - ENGINE 5801858658 IPU 280B TIER4 B (1/16-) (10.304.AS) - DIPSTICK, ENGINE OIL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
781 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASASSY, Dipstick Oil Level, Incl 2 - 3 |
| 2. | NS | [1] | NOT SERVICED | BASDipstick, Incl in 1 |
| 3. | NS | [1] | NOT SERVICED | BASTube, Incl in 1 |
| 4. | 4897330 | [2] | HEX SOCKET PLUG,M12 x 1.5 | TORASSY, Incl 5 - 6 |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 4 |
| 6. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TORIncl with 4 |
| 7. | 4895037 | [1] | EXPANSION PLUG,32.03mm | TOR |
| 8. | NS | [1] | NOT SERVICED | BASPlastic Plug |
| 9. | 2853118 | [1] | BOLT,Hex, M6 x 1 x 18mm | TORM6 x 1mm x 18mm Superseded by part number: 16597225 |
| 11. | NS | [1] | NOT SERVICED | BASBracket |
| 12. | 4895406 | [2] | EXPANSION PLUG,9.8mm OD | TOR |
| 14. | NS | [1] | NOT SERVICED | BASO-ring |
