HK51011
|
[1] |
KIT hydraulic, pickup lift, complete, to be ordered through wholegoods only
|
|
| 1. |
700710252
|
[1] |
ORIFICE
|
CAS
9/16"-18, plate, .038
|
| 2. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
Includes: Ref. 11 Superseded by part number: 76344, 72186128
|
| 3. |
700719095
|
[2] |
HYDRAULIC HOSE,0.25" ID x 177.17", SAE J516, SAE J343
|
HFI
hydraulic
|
| 4. |
700707498
|
[2] |
ELBOW
|
CAS
90°, includes: REF. 10
|
| 5. |
700150179
|
[1] |
SPACER
|
HFI
|
| 6. |
700150178
|
[1] |
CLAMP
|
HFI
|
| 7. |
434-616
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 80280503
|
| 8. |
232-5316
|
[3] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8"-16, hex. flange top lock, GR/G Superseded by part number: 86521609
|
| 9. |
700153662
|
[1] |
GROMMET
|
HFI
|
| 10. |
700717627
|
[1] |
CLAMP
|
HFI
line
|
| 11. |
700716327
|
[1] |
CYLINDER
|
CAS
ASSY., hydraulic
|
| 12. |
432-1020
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
Superseded by part number: 86523851
|
| 13. |
063875
|
[1] |
CLEVIS PIN
|
CAS
1/2" x 2-1/2"
|
| 14. |
495-21044
|
[2] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 15. |
121-237
|
[1] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8"-16 x 1-1/4", hex. flange, GR8 Superseded by part number: 87327172
|
| 16. |
738468
|
[1] |
O-RING
|
IH
|
| 17. |
237-6004
|
[1] |
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
|
CAS
Superseded by part number: 165202, 72186131
|
