| 1. |
241-1316
|
[2] |
LINK,19.05mm Pitch
|
CAS
CHAIN roller, #60, 10 foot bulk
|
| 3. |
861468
|
[1] |
KEY
|
HFI
5/16" x 2-3/4", Gib
|
| 4. |
700135575
|
[1] |
SPROCKET ASSY.
|
HFI
WA, 23 tooth
|
| 5. |
95-81182
|
[2] |
WASHER,0.81" ID x 1.25" OD x 0.07" Thk
|
CAS
GAUGE 3/4" x 14, narrow rim machinery bushing
|
| 6. |
95-81051
|
[2] |
WASHER,19.84mm ID x 31.75mm OD x 3.81mm Thk
|
CAS
GAUGE 3/4" x 10, narrow rim machinery bushing
|
| 7. |
700105787
|
[1] |
SPACER
|
HFI
|
| 8. |
700135570
|
[1] |
SPROCKET ASSY.
|
HFI
includes: REF. 20 & 21
|
| 9. |
700135550
|
[1] |
SPACER
|
HFI
|
| 10. |
7770787
|
[1] |
FITTING,Sq Nk, 1/2" - 13 x 4", Gr 5, Full Thd
|
CAS
1/2"-13 x 4", full thread round head square neck bolt
|
| 11. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 12. |
700135564
|
[1] |
MOUNTING PARTS
|
HFI
WA
|
| 13. |
700135944
|
[1] |
SHIELD
|
HFI
|
| 14. |
7883366
|
[2] |
SCREW,Hex Washer, 3/8" - 16 x 1/2"
|
CAS
3/8"-16 x 1/2", hex. washer head machine
|
| 15. |
433-620
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
Superseded by part number: 86508773
|
| 16. |
496-11041
|
[4] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8", hardened, plain Superseded by part number: 86632588
|
| 17. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8"-16, hex. flange top lock, GR/G Superseded by part number: 86521609
|
| 18. |
413-1272
|
[1] |
BOLT,Hex, 3/4" - 10 x 4-1/2", Gr 5
|
CAS
3/4"-10 x 4-1/2", hex. cap screw Superseded by part number: 88007
|
| 19. |
492-11075
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 20. |
100-21175
|
[2] |
SNAP RING,1.75", Int, #175
|
CAS
Superseded by part number: 66967
|
| 21. |
T39594
|
[1] |
BALL BEARING,0.7505" ID x 1.7805" OD x 0.61"
|
CAS
Superseded by part number: 87029275
|
