凯斯零件查询(RS561A) - CASE IH ROUND BALER (1/99-12/00) (2-028) - PUMP DRIVE ASSEMBLY, LOWER RIGHT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
607 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
1791D
|
[1] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
roller, #50, 10 foot bulk
|
| 2. |
241-1315
|
[1] |
LINK, CONNECTING
|
CAS
#50, clip Superseded by part number: 87034815
|
| 3. |
195-2091
|
[2] |
WASHER,15/16" x 1 3/8" x .219"
|
CAS
GAUGE 7/8" x 14, narrow rim machinery bushing
|
| 4. |
700132752
|
[1] |
SPROCKET ASSY.
|
HFI
50B15
|
| 5. |
700716888
|
[1] |
SPROCKET ASSY.
|
CAS
idler, 50-17
|
| 6. |
52811
|
[2] |
RING, SNAP
|
HFI
RING SNAP ext., retaining
|
| 7. |
95-81100
|
[2] |
WASHER,33/64" x 7/8" x .049"
|
CAS
GAUGE 1/2" x 18, narrow rim machinery bushing Superseded by part number: 86639334
|
| 8. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2", hardened, plain
|
| 9. |
6181002
|
[1] |
SPACER
|
CAS
|
| 10. |
483-1386
|
[2] |
SET SCREW,Hex Soc, 3/8"-16 x 3/8"
|
CAS
3/8"-16 x 3/8", cup point hex. socket set, NP Superseded by part number: 86624120
|
| 11. |
700132751
|
[1] |
SPROCKET ASSY.
|
HFI
WA, 50B36
|
| 12. |
591514R1
|
[1] |
CARRIAGE BOLT,1/2" - 13 x 2 3/4", Grade 5
|
IH
1/2"-13 x 2 3/4", round head square neck bolt Superseded by part number: 88955
|
| 13. |
231-5348
|
[1] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2"-13, hex. flange top lock, GR/G Superseded by part number: 86521610
|
