凯斯零件查询(RS561A) - CASE IH ROUND BALER (1/99-12/00) (4-004) - ELECTRICAL ASSEMBLY, TWINE ARM SENSOR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
244 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
515-23190
|
[1] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86624005
|
| 2. |
409-7612
|
[1] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 3. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8"-16, hex. flange top lock, GR/G Superseded by part number: 86521609
|
| 4. |
286476
|
[1] |
SPACER
|
CAS
|
| 5. |
7702079
|
[1] |
SCREW
|
CAS
3/8"-16 x 2-1/2", hex. flange, GR8
|
| 6. |
496-11041
|
[1] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8", hardened, plain Superseded by part number: 86632588
|
| 7. |
700132675
|
[1] |
SHAFT
|
HFI
|
| 8. |
731489
|
[1] |
O-RING
|
HFI
|
| 9. |
700132674
|
[1] |
PLATE
|
HFI
|
| 10. |
700719116
|
[1] |
BUSHING,8.872 mm ID x 25.5 mm OD x 15 mm
|
HFI
|
| 11. |
700719115
|
[1] |
SNAP RING
|
HFI
retaining, external
|
| 12. |
700717503
|
[1] |
O-RING
|
HFI
|
| 13. |
700719117
|
[1] |
INDICATOR
|
HFI
position Superseded by part number: 700155670
|
| 14. |
37152155
|
[2] |
PIN
|
A
#10-24 x 1-1/4", cross recess pan head machine screw, GR, 60M
|
