凯斯零件查询(RS561A) - CASE IH ROUND BALER (1/99-12/00) (4-006) - ELECTRICAL ASSEMBLY, TWINE RUN AND BALE SWITCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
667 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
225127C1
|
[1] |
PLUG
|
CAS
PLUG 2 way Superseded by part number: 87686742
|
| 2. |
700710211
|
[2] |
ACTUATOR
|
IH
ACTUATOR
|
| 3. |
L18337
|
[2] |
CABLE TIE,9.95"-12.1" lg
|
CAS
CABLE STRAP TIE Superseded by part number: 529070
|
| 4. |
700119161
|
[2] |
SWITCH
|
L
SENSOR "A"
|
| 5. |
121-115
|
[2] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 6. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16"-18, hex. flange top lock, GR/G
|
| 7. |
700132672
|
[1] |
LEVER
|
HFI
WA
|
| 8. |
731489
|
[1] |
O-RING
|
HFI
|
| 9. |
700132673
|
[1] |
PLATE
|
HFI
|
| 10. |
700719116
|
[1] |
BUSHING,8.872 mm ID x 25.5 mm OD x 15 mm
|
HFI
|
| 11. |
700719115
|
[1] |
SNAP RING
|
HFI
retaining, external
|
| 12. |
700717503
|
[1] |
O-RING
|
HFI
|
| 13. |
700719117
|
[1] |
INDICATOR
|
HFI
position Superseded by part number: 700155670
|
| 14. |
37152155
|
[2] |
PIN
|
A
#10-24 x 1-1/4", cross recess pan head machine screw, GR, 60M
|
