纽荷兰零件查询(DC85) - CRAWLER DOZER (8/04-) (04-11) - HARNESS, ENGINE AND REAR WIRE HARNESS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
302 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87438048 | [1] | WIRE HARNESS | BURMain, No Longer Available, For Service Order 87319008 Main Harness and 87318846 Windshield and Door Washer Harness (Models With Cab) (Ref 16) Superseded by part number: 87319008 |
| 1A. | 87319008 | [1] | WIRE HARNESS | BURMain, Replaces 87438048 |
| 2. | L18331 | [1] | CABLE TIE,375.9mm L | CAS Superseded by part number: 529070 |
| 3. | 87438047 | [1] | WIRE HARNESS | BURMicroController To Pump Motor; No Longer Available, Replaced By 419302A1 Harness (REF3A) And 87310025 Harness (REF 4) Superseded by part number: 419302A1, 87310025 |
| 3A. | 419302A1 | [1] | WIRE HARNESS | BURMicroController To Pump Motor; Along With 87310025 Harness (REF 4) Replaces 87438047 Harness |
| 4. | 87310025 | [1] | WIRE HARNESS | BURJumper Harness; Engine Speed Pickup |
| 5. | 86982398 | [1] | SPACER | BURNylon Spacer; At Fuse Block, Diodes and Cab and Microcontroller Areas |
| 6. | 201-119 | [1] | FITTING | CAS1/4 ORFS x 1/2 ORB; Incl. Ref 7, 8 |
| 7. | 238-6011 | [1] | O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9825770 |
| 8. | 237-6008 | [1] | O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro | CASBoss end Superseded by part number: 128825 |
| 10. | 201-421 | [1] | TEE,9/16"-18 ORFS x 9/16"-18 Sw Run | CASAt Tandem Pump; Incl. Ref 11 |
| 12. | 87403648 | [1] | PRESSURE SWITCH | BURCharge; At Tee On Tandem Pump |
| 13. | 86982400 | [1] | SPACER | NH |
| 14. | 419176A1 | [1] | WIRE HARNESS | BURRear |
