纽荷兰零件查询(DC85) - CRAWLER DOZER (8/04-) (04-13) - HARNESS, FRONT CONSOLE AND SWITCHES - CANOPY, ROPS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
942 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87441568 | [1] | WIRE HARNESS | BURFront Console; Canopy Models |
| 2. | 87434892 | [1] | CLUSTER, INSTR. | BURInstrument Cluster, See Figure 04-18A |
| 3. | 87026656 | [2] | SCREW,Phillips Drive, Pan HD, M5 x 25mm, Cl 4.8 | BURM5 x 25; 4.8 |
| 4. | 86000535 | [1-2] | PLUG,1.427" x .62", Plastic | WINSwitch Hole |
| 5. | 87416177 | [1] | IGNITION SWITCH | FARIncludes Keys |
| . . | 86502201 | [1] | IGNITION KEY | WINOn Ring Superseded by part number: 47457834 |
| 7. | 76067216 | [2] | COVER | LECFuse Panel |
| . . | A149802 | [1] | FUSE | CAS20 Amp; Yellow; Upper Fuse Box Superseded by part number: 9804895 |
| . . | A149799 | [1] | FUSE | CAS7.5 Amp; Brown; Upper Fuse Box Superseded by part number: 87717079 |
| . . | A149798 | [3] | FUSE | CAS5 Amp; Tan; Lower Fuse Box Superseded by part number: 87693742 |
| . . | A149800 | [2] | FUSE | CAS10 Amp; Red; Lower Fuse Box Superseded by part number: 9811773 |
| 8. | 87438286 | [1] | LIGHT SWITCH | CASRocker; Front Work Lamps |
| 9. | 133715A1 | [1] | LIGHT SWITCH | CASRocker; Rear Work Lamps |
| 10. | 87410087 | [1] | ROCKER SWITCH | BURRocker; Momentary, Up/Down |
| 11. | 87410091 | [1] | ROCKER SWITCH | BURRocker; Momentary, Display |
| 12. | 386852A2 | [1] | SWITCH | CASRocker; Horn |
