神钢零件查询(F4HFE6132 A003) - ENGINE 5801753676 - 47541755 (1/14-) (10.304.AJ) - ENGINE OIL, DIPSTICK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
561 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2855212 | [1] | ASSY, Incl 2 - 5 | |
| 3. | 4898502 | [1] | O-RING,0.364" ID x 0.504" OD x 0.07" | LEC Superseded by part number: 17277981 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONHandgrip, Incl in 1 |
| 6. | 4895406 | [3] | EXPANSION PLUG,9.8mm OD | TOR |
| 7. | 4897330 | [2] | HEX SOCKET PLUG,M12 x 1.5 | TORASSY, Incl 6, 7 |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 7 |
| 9. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 10. | 4895037 | [1] | EXPANSION PLUG,32.03mm | TOR |
