凯斯零件查询(RS561A) - CASE IH ROUND BALER (1/99-12/00) (8-036) - KICKER HYDRAULIC ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
674 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700714707
|
[2] |
CYLINDER
|
CAS
ASSY. hydraulic
|
| 2. |
700714806
|
[1] |
HYDRAULIC HOSE,0.25" ID x 39.37", SAE J517, SAE J516, SAE J343
|
CAS
hydraulic
|
| 3. |
306132C1
|
[4] |
CABLE TIE,14.5" L
|
IH
CABLE STRAP TIE Superseded by part number: 435437A1
|
| 4. |
121-226
|
[1] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 5. |
232-5316
|
[1] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8"-16, hex. flange top lock, GR/G Superseded by part number: 86521609
|
| 6. |
7041015
|
[1] |
CLAMP
|
CAS
line
|
| 7. |
700719098
|
[1] |
HOSE
|
HFI
hydraulic
|
| 8. |
700719097
|
[1] |
HOSE
|
HFI
hydraulic
|
| 9. |
218-5105
|
[4] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
Includes: Ref. 10 Superseded by part number: 76344, 72186128
|
| 10. |
738468
|
[1] |
O-RING
|
IH
9/16"
|
| 11. |
218-5243
|
[2] |
TEE,9/16" - 18 Male JIC x 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
Includes: Ref. 10 Superseded by part number: 86513020
|
| 12. |
700719103
|
[1] |
HYDRAULIC HOSE,0.25" ID x 23.62"
|
HFI
hydraulic
|
