凯斯零件查询(RS561A) - CASE IH ROUND BALER (1/99-12/00) (8-034) - HYDRAULIC CYLINDER ASSEMBLY, THREADER, 700719879 COMPLETE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
148 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700719879
|
[1] |
CYLINDER
|
HFI
ASSY. hydraulic, complete, 2-1/2 in. bore x 12 in.stroke
|
| 2. |
774315
|
[1] |
NUT
|
CAS
7/8"-14, hex. top lock, GR/C
|
| 3. |
700710421
|
[1] |
PISTON
|
CAS
|
| 4. |
700719881
|
[1] |
PISTON ROD
|
HFI
|
| 5. |
700719882
|
[1] |
GUIDE
|
HFI
rod
|
| 6. |
700719883
|
[1] |
SEAL KIT
|
HFI
KIT and o-ring repair, Includes items in art marked with asterisk
|
