| 1. |
8027427
|
[1] |
GROMMET
|
CAS
|
| 2. |
700719123
|
[2] |
HYDRAULIC HOSE,0.38" ID x 157.48"
|
HFI
hydrtaulic
|
| 3. |
218-845
|
[2] |
TEE,37 Degree, 3/4"-16 x 3/4"-16, Fem Sw Run
|
CAS
3/4", 37° taper, straight thread, MFM Superseded by part number: 86511870, 72186150
|
| 4. |
218-5351
|
[1] |
HYD CONNECTOR,3/4"-16, 37 Degree x 9/16"-18, O-Ring
|
CAS
straight, 9/16" ORBM x 3/4" JICM, includes: REF. 22 Superseded by part number: 86509028
|
| 5. |
413-672
|
[2] |
BOLT,Hex, 3/8" - 16 x 4-1/2", Gr 5
|
CAS
3/8"-16 x 4-1/2", hex. cap screw Superseded by part number: 86505980
|
| 6. |
495-21056
|
[2] |
WASHER,1/2"
|
CAS
wide, plain 1/2" Superseded by part number: 72187265, 80700
|
| 7. |
232-5316
|
[3] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8"-16, hex. flange top lock, GR/G Superseded by part number: 86521609
|
| 8. |
218-5230
|
[2] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree Fem Sw
|
CAS
JICM x JICF Superseded by part number: 72187024, 248974
|
| 9. |
218-5106
|
[1] |
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
|
CAS
Includes Ref 23 Superseded by part number: 72186176, 128830
|
| 10. |
281-34912
|
[1] |
SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8"-16 x 3/4", hex. washer head thread cutting tapping
|
| 11. |
409-7612
|
[1] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 12. |
S95446
|
[5] |
CLAMP,1 5/16", Insul, 1/2" Bolt
|
CAS
1.25
|
| 13. |
218-5128
|
[1] |
ELBOW,90° Elbow, 9/16" - 18 Male JIC x 3/4" - 16 Male ORB
|
CAS
Incl. 23 Superseded by part number: 87329788
|
| 14. |
218-980
|
[2] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw
|
CAS
JICM, JICF Superseded by part number: 72186136, 86629586
|
| 15. |
218-5057
|
[1] |
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
|
CAS
Incl. Ref. 22 Superseded by part number: 76350
|
| 16. |
218-5105
|
[1] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
90°, 9/16" JICM x ORBM, Includes: Ref. 22 Superseded by part number: 76344, 72186128
|
| 17. |
700717511
|
[1] |
MANIFOLD VALVE
|
HFI
ASSY. hydraulic
|
| 18. |
218-5058
|
[1] |
HYD CONNECTOR,9/16" - 18 Male JIC x 3/4" - 18 Male ORB
|
CAS
straight, 3/4" ORBM x 9/16" JICM, includes: REF. 23 Superseded by part number: 128817, 72186139
|
| 19. |
218-5059
|
[1] |
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
|
CAS
Straight, ORBM, JICM, Incl. Ref 23 Superseded by part number: 128818
|
| 20. |
700712122
|
[1] |
CYLINDER
|
CAS
ASSY. hydraulic
|
| 21. |
700719124
|
[2] |
HYDRAULIC HOSE,0.38" ID x 181.10", SAE 100R2, SAE J517
|
HFI
hydraulic
|
| 22. |
738468
|
[1] |
O-RING
|
IH
|
| 23. |
237-6008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
Superseded by part number: 128825
|
