神钢零件查询(F4HFE6132 A003) - ENGINE 5801753676 - 47541755 (1/14-) (55.015.AA) - ENGINE, CONTROL, UNIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
369 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504388754 | [1] | CONTROL UNIT | TOR Superseded by part number: 84499733 |
| 3. | 504297839 | [1] | BRACKET | TOR |
| 4. | 16586025 | [2] | SCREW,Hex, M6 x 30mm | TOR Superseded by part number: 2854083 |
| 5. | 17935001 | [4] | SELF-TAP SCREW,Hex Flng, M5.5 x 1.8 x 45mm | TOR |
| 8. | 4899078 | [3] | SCREW,Hex Flg, M8 x 1.25 x 45 | TOR |
| 9. | 98498817 | [6] | ISOLATOR | TOR Superseded by part number: 2855150 |
| 13. | 18137825 | [2] | BOLT,Hex, M6 x 16mm | TOR |
