神钢零件查询(F4HFE6133 B003) - ENGINE 5801843802 - 47637346 TIER4 B (1/13-) (10.250.AD) - TURBOCHARGER OIL SUPPLY LINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
384 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2857015 | [1] | HYD CONNECTOR,Hex, M12 x 1.5 x 6.7mm ID x 32mm L | TORASSY, Incl 2 - 4 Superseded by part number: |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONJunction, Incl in 1 |
| 3. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 4. | 4899108 | [1] | O-RING,0.364mm ID x 0.07mm Width | TOR Superseded by part number: 17277981 |
| 5. | 2852380 | [1] | BRACKET | TOR Superseded by part number: 99477631 |
| 6. | 4895579 | [1] | CLAMP | LEC Superseded by part number: 4899436 |
| 7. | 4899068 | [1] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
| 8. | 2852746 | [1] | HOSE,6.35mm ID x 698mm L | TOR Superseded by part number: 504084096 |
| 9. | 4895089 | [1] | PLUG,0.886" L | TOR |
