纽荷兰零件查询(DC85) - CRAWLER DOZER (8/04-) (09-56) - DECALS - LATIN AMERICAN SPANISH New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
183 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 334034A1 | [2] | WARNING DECAL | CASEntanglement Hazard |
| 3. | 389736A1 | [2] | DECAL | CASDanger; Jump Start, Battery |
| 4. | 389741A1 | [1] | DECAL | CASWarning; Radiator Cap |
| 5. | 124271A1 | [1] | DECAL | CASWarning; Do Not Jump |
| 6. | 87352602 | [1] | DECAL | BURWarning; Read the Operator's Manual; Replaces 334000A2 |
| 8. | 124281A1 | [1] | DECAL | CASDanger; Engine Start Warning |
| 9. | 87421171 | [1] | DECAL | BURDozer Blade Control Pattern |
| 10. | 87451954 | [1] | LARGE PLATE | CASPLATE, LARGE Decal Mounting, Used With Ref 3, 8, 11, 12 |
| 11. | 614-10025 | [2] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8 | CAS Superseded by part number: 11106231 |
| 12. | 140028 | [2] | WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | NH |
| 13. | 87355182 | [1] | DECAL | BURImportant; Track Tension; Replaces 87421173 |
| 20. | 87422190 | [1] | DECAL | BURRipper Control Pattern |
| 21. | 76067229 | [1] | DECAL | LECAt 12 Volt Plug Receptacle; Cab Models |
| 22. | NSS | [1] | NOT SERVICED SEPARATELY | CONNorth American Decal |
| 24. | 8603094 | [1] | WARNING DECAL | FARExplosion Hazard, Do Not Use Ether |
