纽荷兰零件查询(DC95) - CRAWLER DOZER (8/04-) (02-06) - AIR CLEANER - MOUNTING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
813 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | L10659 | [1] | CAP | CASIncludes Clamp Superseded by part number: BN25290 |
| 2. | 87434700 | [1] | AIR CLEANER | BURSee Figure 02-07 |
| 3. | 844-10030 | [4] | BOLT,Hvy Hex, M10 x 30mm, Cl 8.8 | CAS Superseded by part number: 9840672 |
| 3A. | 39519 | [4] | WASHER,10.31mm ID x 34.9mm OD x 3.57mm Thk | CAS |
| 4. | 832-44610 | [4] | FLANGE NUT,M10 x 1.5, Flg, Cl 10 | BRRM10 Superseded by part number: 86981467 |
| 5. | 429533A1 | [1] | RADIATOR HOSE,114.30 mm ID x 150.00 mm, SAE J200, SAE J20 | BUR Superseded by part number: 87521376 |
| 6. | 214-3180 | [4] | HOSE CLAMP,4-1/4" - 5-1/8", HD Worm | CAS5 inch Superseded by part number: 86633351 |
| 7. | 87431920 | [1] | LARGE HOSE | BURHOSE,LARGE |
| 8. | 86988018 | [1] | AIR INTAKE | BURIncludes Clamp; Component Parts Not Serviced Separately; If Used |
| 9. | 86988015 | [1] | ADAPTER | BURRubber |
| 10. | 87433761 | [1] | HOSE | BUR |
| 11. | 214-1424 | [2] | HOSE CLAMP,#24, 1.06" - 2", Type F Worm | CAS Superseded by part number: 513309 |
| 12. | L17985 | [1] | FITTING | CAS |
