纽荷兰零件查询(DC95) - CRAWLER DOZER (8/04-) (02-22) - MANIFOLD - EXHAUST New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
755 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852335 | [1] | EXHAUST MANIFOLD | TOR Superseded by part number: 504009272 |
| 2. | 2830445 | [6] | MANIFOLD GASKET | TOR Superseded by part number: 504081248 |
| 3. | 2852744 | [8] | SCREW,Flng, M10 x 1.5 x 65mm | TOR |
| 4. | 4895336 | [12] | SPACER | TORSpacer Superseded by part number: 47464712 |
| 5. | 4899085 | [4] | STUD,M10 x 1.5 x 42mm | TOR |
| 7. | 2852745 | [4] | SCREW | TOR Superseded by part number: |
