纽荷兰零件查询(DC95) - CRAWLER DOZER (8/04-) (02-34) - OIL FILTER AND COOLER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
717 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899019 | [15] | SCREW,Hex Flg, M8 x 1.25 x 35 | TOR |
| 2. | 2853782 | [1] | OIL COOLER | TORHEAD ASSEMBLY, Incl. Ref 3 - 8 Superseded by part number: 4896410, 4896404, 4895045, 504096409, 4899643 |
| 3. | 2853781 | [1] | PLUG | TORPLUG Superseded by part number: 504096409 |
| 4. | 4896404 | [1] | PLUNGER | TORPlunger, Pressure Regulator |
| 5. | 4895045 | [1] | SPRING | TOR |
| 6. | 4899035 | [1] | O-RING,2.62mm Thk x 18.39mm ID | TOR |
| 7. | J936365 | [1] | PRESSURE RELIEF VALVE | CASPressure Relief Superseded by part number: 4896410 |
| . . | 4899643 | [1] | FILTER HEAD | TORIncl. 8 |
| 8. | 4893391 | [1] | ADAPTER,M24 x 2 x M27 x 2 | TOR Superseded by part number: J936365 |
| 9. | 4896407 | [1] | OIL COOLER | TORCooler Core Superseded by part number: |
| 10. | 2830559 | [1] | GASKET,0.5mm Thk | TORCore |
| 11. | 4896409 | [1] | GASKET,1.55mm Thk | TORHead |
