神钢零件查询(F4HFE6136 B003) - ENGINE 5801939277 47603479 SPRAYER PATRIOT 2250 T4B (7/15-) (10.304.AR) - PISTON COOLING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
330 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852202 | [6] | NOZZLE, PISTON COOLI | TORASSY, Incl 2, 3 Superseded by part number: 5801910166, 5801639154 |
| 2. | 4894218 | [1] | SCREW,Special, M8 x 20 | TORM8 x 1.25 x 20 |
| 2. | 2852323 | [1] | SCREW,M8 x 1.25 x 14mm | TOR Superseded by part number: 16597925 |
| 3. | 2852203 | [1] | NOZZLE, PISTON COOLI | TOR Superseded by part number: 5801910166, 5801639154 |
