神钢零件查询(F4HFE6136 B003) - ENGINE 5801939277 47603479 SPRAYER PATRIOT 2250 T4B (7/15-) (10.304.AS) - DIPSTICK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
948 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | 4898502 | [1] | O-RING,0.364" ID x 0.504" OD x 0.07" | LEC Superseded by part number: 17277981 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONSleeve, Incl in 1 |
| 5. | 4897330 | [1] | HEX SOCKET PLUG,M12 x 1.5 | TORASSY, Incl 6, 7 |
| 6. | 4895610 | [2] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 5 |
| 8. | 4895406 | [3] | EXPANSION PLUG,9.8mm OD | TOR |
