凯斯零件查询(8520) - CASE IH RECTANGULAR BALER (1/88-12/99) (2-02) - TONGUE AND PRIMARY DRIVE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
375 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
705582
|
[8] |
WASHER
|
CAS
5/8 HARDENED PLAIN WASHER Superseded by part number: 396-21066, 396-21066, NLS
|
| 2. |
7701758
|
[8] |
BOLT,Hex, 5/8" - 11 x 1 1/2", Gr 5
|
CAS
5/8-11 X 1-1/2 C Superseded by part number: 88062
|
| 3. |
705061
|
[8] |
PLUG
|
NNA
5/8" Superseded by part number: 492-11062
|
| 4. |
704130
|
[8] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
| 5. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 6. |
7701188
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 C Superseded by part number: 87670
|
| 7. |
704742
|
[2] |
ROD
|
NNA
1/2-13 HFTLN GR/G Superseded by part number: 231-5348, 231-5348, 86516877
|
| 8. |
6355697
|
[2] |
LINK
|
CAS
BUSHING
|
| 9. |
758441
|
[1] |
SPRING
|
IH
- tension
|
| 10. |
700112487
|
[1] |
GUARD
|
HFI
WINDGUARD (8520)
|
| . . |
700116634
|
[1] |
GUARD
|
HFI
WINDGUARD (8530)
|
| 11. |
700112492
|
[3] |
SUPPORT
|
CAS
- clip
|
| 12. |
702035
|
[3] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 X 1-1/4 C
|
| 13. |
705038
|
[3] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 14. |
700112491
|
[1] |
SHIELD
|
CAS
- PTO
|
| 15. |
70417
|
[3] |
BOLT
|
CAS
1/4-20 X 1/2 CRTHMS
|
| 16. |
74781
|
[6] |
NUT
|
CAS
3/8-16 LHSN Superseded by part number: 231-1406, 231-1406, NS
|
| 17. |
700709603
|
[6] |
WASHER,3/8"
|
CAS
3/8 WIDE PLAIN WASHER Superseded by part number: 80702
|
| 18. |
58107
|
[6] |
SPRING
|
IH
- compression
|
| 19. |
1662964
|
[1] |
LARGE PLATE
|
CAS
PLATE - pressure
|
| 20. |
852749
|
[1] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| 21. |
700112494
|
[1] |
DISC
|
CAS
WA - plate
|
| 22. |
700710945
|
[2] |
CLUTCH PLATE,126.75mm ID x 203.2mm OD x 3.18mm Thk
|
L
DISC - clutch
|
| 23. |
700112497
|
[1] |
PLATE
|
CAS
PILOT WA - clutch
|
| 24. |
7772767
|
[6] |
SCREW,Hex, 3/8" - 16 x 3 1/2", Gr 5
|
CAS
3/8-16 X 3-1/2 C Superseded by part number: 88959
|
| 25. |
700112476
|
[1] |
TOW BAR
|
HFI
TONGUE WA
|
