凯斯零件查询(8520) - CASE IH RECTANGULAR BALER (1/88-12/99) (3-08) - PICKUP TINE ASSEMBLY, (8520 ONLY) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1008 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
062307
|
[6] |
1/4 X 2 COTTER PIN
|
|
| 2. |
700108622
|
[6] |
FLANGED BEARING
|
L
FLANGE - bearing
|
| 3. |
7700065
|
[12] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| 4. |
705038
|
[12] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 5. |
704023
|
[12] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 6. |
700112381
|
[1] |
ROTOR
|
HFI
SHAFT - pickup
|
| 7. |
700047
|
[33] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 8. |
704247
|
[33] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| 9. |
701367
|
[3] |
HEX SOC SCREW,3/8"-16 x 2 1/4"
|
CAS
3/8-16 X 2-1/4 HSHCS SPL Superseded by part number: 61-636
|
| 10. |
710392
|
[6] |
BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm
|
L
BEARING - cylindrical Superseded by part number: 84330047
|
| 11. |
700108618
|
[3] |
ARM
|
L
CRANK WA - tine bar
|
| 12. |
700705612
|
[3] |
CAM FOLLOWER
|
L
BEARING - cam, follower Superseded by part number: 86536275
|
| 13. |
700707867
|
[3] |
NUT
|
CAS
1/2-20 HFTLN GR/G Superseded by part number: 87033645
|
| 14. |
88902
|
[3] |
NUT,3/8"-16
|
NH
3/8-16 HCLN GR/B
|
| 15. |
705533
|
[33] |
WASHER
|
NNA
3/8 HARDENED PLAIN WASHER Superseded by part number: 496-11041, 496-11041, 80702
|
| 16. |
700703860
|
[33] |
REEL TINE,Coiled, 2 Prongs, 164mm L
|
CAS
TINE - double
|
| 17. |
700112386
|
[3] |
CHANNEL
|
HFI
WA - tine
|
