凯斯零件查询(8530) - CASE IH RECTANGULAR BALER (1/88-12/99) (9-08) - DECALS AND LOCATION DIAGRAM - LEFT, (8530 ONLY) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
653 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
878660
|
[1] |
REFLECTOR
|
IH
- red
|
| 2. |
7778368
|
[1] |
DECAL
|
CAS
- warning (Keep hands away)
|
| 3. |
78311
|
[1] |
DECAL
|
CAS
- caution (Keep all shields) Superseded by part number: 700714229
|
| 4. |
7889306
|
[1] |
DECAL
|
CAS
- grease
|
| 5. |
700710005
|
[1] |
DECAL
|
CAS
- combo, left front
|
| 6. |
700706289
|
[1] |
DECAL
|
CAS
- operation (Stuffer timing)
|
| 7. |
700708731
|
[1] |
DECAL
|
CAS
- shearbolt
|
| 8. |
1973424C1
|
[1] |
DECAL
|
IH
- Case International
|
| 9. |
700703905
|
[2] |
DECAL
|
CAS
- operation (Twine only)
|
| 10. |
700700036
|
[2] |
DECAL
|
CAS
- danger (Serious injury)
|
| 11. |
700706207
|
[2] |
DECAL
|
CAS
- warning (Do not adjust)
|
| 12. |
700709866
|
[4] |
WASHER
|
CAS
- washer, camloc
|
| 13. |
700709867
|
[4] |
DECAL
|
CAS
- slot, camloc
|
| 14. |
700703441
|
[1] |
DECAL
|
CAS
- operation (Twine knot detail)
|
| 15. |
700704658
|
[1] |
DECAL
|
CAS
- needle timing
|
| 16. |
700710104
|
[1] |
DECAL
|
CAS
- combo, left rear
|
