纽荷兰零件查询(FD145) - CRAWLER DOZER (N.A. VERSION) (10/98-) (5.655[01]) - HEATER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
397 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79107307 | [1] | LEVER | LEC |
| 2. | 79107221 | [1] | CABLE | LEC |
| 3. | 79106520 | [1] | BRACKET | LEC |
| 4. | 79106521 | [2] | PIN | LEC |
| 5. | 79107306 | [2] | BLOCK | LEC |
| 6. | 4982514 | [2] | CABLE TIE | LEC370 Superseded by part number: 87615202 |
| 7. | 10445831 | [2] | BOLT,Hex, M4 x 8mm, Cl 10.9, Full Thd | LEC8X4 |
| 8. | 10403580 | [1] | RING | MKT10X1,5 |
| 9. | 12575421 | [2] | NUT | LEC |
| 10. | 14496431 | [2] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 11. | 15645501 | [2] | SELF-TAP SCREW,Cross Pan Hd, M4.8 x 16mm | LEC Superseded by part number: 15645570 |
| 12. | 79092755 | [1] | DECAL | LEC |
| 13. | 79089651 | [1] | KNOB | LEC |
| 14. | 79079424 | [1] | CLIMATE CONTROL SWITCH | LEC |
