神钢零件查询(F4HFE6137 B003) - ENGINE 5801925169 47748446 TC 5.80 TIER 4B (1/12-) (10.250.AD) - TURBOCHARGER LUBE LINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
242 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2857015 | [1] | HYD CONNECTOR,Hex, M12 x 1.5 x 6.7mm ID x 32mm L | TOR Superseded by part number: |
| 1. | 504329209 | [1] | UNION | UNION |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 1 |
| 3. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 4. | 4899108 | [1] | O-RING,0.364mm ID x 0.07mm Width | TOR Superseded by part number: 17277981 |
| 4. | 17277981 | [1] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 7, 75 Duro | TOR Superseded by part number: 14452981 |
| 5. | 504360668 | [1] | TUBE,TUBE | TUBE,TUBE |
| 6. | 4895089 | [1] | PLUG,0.886" L | TOR |
