纽荷兰零件查询(FD145) - CRAWLER DOZER (N.A. VERSION) (10/98-) (9.440[01]) - FRONT IMPLEMENT ALL HYDR.- C-FRAME - OPTIONAL CODE 76035980 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
299 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79098545 | [1] | U-FRAME | LEC- ASSY |
| 2. | 76041271 | [1] | SUPPORT | LEC |
| 3. | 79101029 | [4] | PIN | LEC Superseded by part number: 84306890 |
| 4. | 76028733 | [2] | COVER PLATE | LEC |
| 5. | 76041248 | [1] | PIN | LEC Superseded by part number: 76090823 |
| 6. | 15981031 | [10] | BOLT,Hex, M16 x 1.5 x 55mm, Cl 10.9 | TTF |
| 7. | 14496931 | [10] | WASHER,17mm ID x 30mm OD x 3mm Thk | IMO Superseded by part number: 86625266 |
| 8. | 11115631 | [2] | BOLT,Hex, M14 x 35, 10.9, Full Thd | LEC |
| 9. | 12644931 | [2] | WASHER,14.4mm ID x 32mm OD x 4mm Thk | LEC |
| 10. | 76041081 | [2] | BUSHING,60.19mm ID x 80mm OD x 63mm L | LEC |
| 11. | 79093360 | [1] | COVER PLATE | LEC |
| 12. | 79093361 | [2] | PIN | LEC |
| 13. | 79099473 | [2] | PIN | LEC |
| 14. | 79101028 | [2] | PIN,44.8mm OD x 186mm L | LEC Superseded by part number: 84204211 |
| 15. | 79095014 | [20] | SHIM | LEC |
| 16. | 16250031 | [2] | SCREW,M16 x 1.5 x 45mm | LEC16X1,5X45 Superseded by part number: 16250131 |
| 17. | 70928169 | [2] | WASHER | CMI16X35,5X8 Superseded by part number: 70927275 |
| 18. | 76033228 | [2] | COVER PLATE | LEC |
| 19. | 79093379 | [2] | PIN | LEC |
| 20. | 76033229 | [4] | COVER PLATE | LEC |
| 21. | 8296969 | [2] | SPACER,18mm ID x 30mm OD x 13mm L | LEC |
| 22. | 11112231 | [12] | SCREW,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd | LEC Superseded by part number: 398792 |
| 23. | 14496731 | [12] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 24. | 76041089 | [30] | SHIM | LEC1 |
| 25. | 76041091 | [60] | SHIM | LEC1 |
| 26. | 76041090 | [30] | SHIM | LEC1 |
| 27. | 16046131 | [2] | SCREW,Hex, M8 x 100mm, Cl 10.9 | LEC Superseded by part number: 16606824 |
| 28. | 16104121 | [2] | NUT,M8 x 1.25, Cl 10 | LEC Superseded by part number: 17152821 |
