凯斯零件查询(8530) - CASE IH RECTANGULAR BALER (1/88-12/99) (9-60) - BALE THROWER ELECTRICAL SPEED CONTROL ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
325 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
722470
|
[4] |
MOUNTING CLIP
|
CAS
TIE - calbe Superseded by part number: 529070
|
| 2. |
700711380
|
[1] |
HARNESS
|
CAS
- ire
|
| 3. |
755769
|
[1] |
CLAMP
|
HFI
- hose Superseded by part number: 87029955
|
| 4. |
700124210
|
[1] |
BRACKET
|
CAS
|
| 5. |
7701485
|
[1] |
BOLT,Hex, 1/4" - 20 x 2", Gr 5
|
CAS
1/4-20 X 2 C Superseded by part number: 87404
|
| 6. |
1703354
|
[1] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 7. |
700711219
|
[1] |
ACTUATOR
|
CAS
- linear
|
| 8. |
62018
|
[1] |
PIN
|
CAS
1/16 X 1/2 COTTER PIN Superseded by part number: 280236
|
| 9. |
705517
|
[3] |
WASHER
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 496-11028, 496-11028, 70900816
|
| 10. |
700124207
|
[1] |
ARM
|
CAS
ASEMBLY
|
| 11. |
7701964
|
[2] |
SCREW,Hex, 1/4" - 20 x 2 1/2", Gr 5
|
L
1/4-20 X 2-1/2 C Superseded by part number: 87845
|
| 12. |
705012
|
[2] |
LOCK WASHER
|
CAS
1/4" Superseded by part number: 492-11025, 492-11025, 86517257
|
| 13. |
704007
|
[2] |
NUT,1/4"-20, G5
|
CAS
1/4-20 H Superseded by part number: 7770
|
