凯斯零件查询(8530) - CASE IH RECTANGULAR BALER (1/88-12/99) (9-62) - BALE THROWER ELECTRICAL CONTROL BOX ASSEMBLY, (700124194 CONTROL BOX ASSEMBLY COMPLETE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
335 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700124194
|
[1] |
BOX
|
HFI
ASSEMBLY - control complete Superseded by part number: 700124196, 590420, 7723562, 722355, 80680, 700711185, 700710551, 86632588, 700710553, 700124195, 280136, 86508773, 703082, 700711381, 578489, 80700
|
| 1. |
700710553
|
[1] |
HARNESS
|
CAS
- wire
|
| 2. |
1702364
|
[1] |
FUSE
|
HFI
- 15 amp Superseded by part number: 590420
|
| 3. |
7020480
|
[1] |
BOX, FUSE
|
CAS
HOLDER - fuse Superseded by part number: 578489
|
| 4. |
700124195
|
[1] |
TERMINAL BOX
|
CAS
BOX WA - control
|
| 5. |
700711185
|
[1] |
SWITCH
|
HFI
- electrical
|
| 6. |
7723562
|
[1] |
ELECTRICAL WIRE
|
CAS
WIRE - electrical, 12 ga.
|
| 7. |
703082
|
[2] |
SELF-TAP SCREW
|
CAS
#8-32 X 3/8 HWHTCTS
|
| 8. |
700124196
|
[1] |
BOTTOM
|
CAS
- box
|
| 9. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 10. |
700054
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 X 1-1/4 RHSNB Superseded by part number: 86508773
|
| 11. |
80702
|
[1] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 HARDENED PLAIN WASHER
|
| 12. |
705038
|
[1] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 13. |
704023
|
[1] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 14. |
722355
|
[2] |
CABLE
|
CAS
WIRE - electrical
|
| 15. |
700711381
|
[1] |
GROMMET
|
CAS
BUSHING - strain relief
|
| 16. |
700710551
|
[1] |
HARNESS
|
CAS
- wire
|
