纽荷兰零件查询(FD145) - CRAWLER DOZER (N.A. VERSION) (10/98-) (9.470[02]) - TILT CYLINDER - FRONT IMPLEMENT - OPTIONAL CODE 76028815 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
958 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76028811 | [1] | HYDRAULIC HOSE,9.50 mm ID x 2420.00 mm, SAE 100R2 or SAE J1453 | LEC |
| 2. | 76028812 | [1] | HYDRAULIC HOSE,9.50 mm ID x 2625.00 mm, SAE 100R2 or SAE J1453 | LEC |
| 3. | 79100437 | [2] | FLANGE | LEC Superseded by part number: 9992298, 79113056 |
| 4. | 70924110 | [2] | O-RING | LEC3,53X24,99 Superseded by part number: 98458442 |
| 5. | 14420331 | [8] | HEX SOC SCREW,M10 x 1.5 x 35mm, Cl 10.9, Full Thd | LEC |
