纽荷兰零件查询(FD145) - CRAWLER DOZER (N.A. VERSION) (10/98-) (9.480[01]) - ANGLE MOLDBOARD (HA) - OPTIONAL CODE 79111734 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
601 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79092037 | [1] | CUTTING BLADE | LEC- ASSY Superseded by part number: 79092036 |
| 2. | 79104464 | [1] | CUTTING EDGE | LEC- RIGHT IN ALTERNATIVE |
| 2. | 8294273 | [1] | CUTTING EDGE | LEC- RIGHT IN ALTERNATIVE |
| 3. | 79104483 | [1] | CUTTING EDGE | LEC- LEFT IN ALTERNATIVE |
| 3. | 8294274 | [1] | CUTTING EDGE | LEC- LEFT IN ALTERNATIVE |
| 4. | 8280730 | [1] | SEAT/SLOT | LEC |
| 5. | 8282270 | [12] | PLOW BOLT,Plow, M20 x 1.5 x 67mm, Cl 10.9 | LEC |
| 6. | 86015195 | [30] | NUT,M20 x 1.5, Cl 10 | RAC |
| 7. | 14497131 | [30] | WASHER,21mm ID x 37mm OD x 3mm Thk | LEC Superseded by part number: 140021 |
| 8. | 11118731 | [6] | BOLT,Hex, M16 x 45, 10.9 | LEC Superseded by part number: 86508624 |
| 9. | 14496931 | [6] | WASHER,17mm ID x 30mm OD x 3mm Thk | IMO Superseded by part number: 86625266 |
| 10. | 8294271 | [3] | CUTTING EDGE | LEC Superseded by part number: 73117701 |
| 11. | 8273211 | [18] | PLOW BOLT,Plow, M20 x 1.5 x 62mm, Cl 10.9 | LEC |
